FULTON 60J - Page 67

J OIL-E-08 2008
Item Part Number Qty Description Remarks Size
December 2004
1 SA0041 1 Burner assembly complete 40
SA0042 1 Burner assembly complete 50
SA0043 1 Burner assembly complete 60
2 10289 1 Sensor,ame  40-60
3 SA0012 1 Lead, ignition assembly 40 - 60
4 10249 2 Electrode, angle Rajah 40 - 60
5 10321 A/R Cable, ignition 40 - 60
6 040EO331 1 Burner assembly 40
050EO331 1 Burner assembly 50
060EO331 1 Burner assembly 60
7 10128 1 Tube, blast 40 - 60
8 10140 A/R Rope, insulation 12mm 40 - 60
9 10253 2 Electrode, ignition 40 - 60
10 10259 A/R Nozzle 5 g/h 40 - 50
10262 A/R Nozzle 7 g/h 50 - 60
11 10318 1 Spring, eye glass 40 - 60
12 10319 1 Glass, eye Pyrex 40 - 60
13 10325 9 Clip 1/2in. 40 - 60
14 10327 1 Spinner 40 - 60
15 10350 2 Nipple, pressure test 40 - 60
16 10384 1 Plate, top 40 - 60
17 10397 1 Deector  40-60
18 10402 1 Control, damper 40 - 60
19 10581 1 Nipple, pipe 1/8in. x 12in. 40 - 60
20 10595 1 Nipple, pipe 3/4in. x 5in. 40 - 60
21 10627 1 Bush 1in. x 3/4in. 40 - 60
22 10716 2 Elbow 40 - 60
23 10785 6 Bolt 1/4in. x 3/4in. UNC 40 - 60
24 10786 2 Bolt 6 x 16mm plated 40 - 60
25 10796 6 Bolt 8 x 30mm plated 40 - 60
26 10810 2 Grubscrew 1/2in. x 1/4in. 40 - 60
27 10832 7 Nut 40 - 60
28 10842 6 Washer,at  40-60
29 10850 6 Washer, spring 40 - 60
30 10977 2 Washer, eye glass 40 - 60
31 11033 9 Washer,at  40-60
32 SA0008 1 Gate, air 40 - 60
33 11139 8 Washer, spring 1/4in. plated 40 - 60
34 12758 1 Nipple, pipe 1/8in. x 14in. 40 - 60
35 13504 1 Manifold, double nozzle 40 - 60
36 050EO430 1 Plate, burner 40 - 60
37 050EO470 1 Holder, electrode 40 - 60
38 11133 1 Ring, combustion 40 - 60
B2-3-2 BURNER ASSEMBLY, OIL, 40 - 60
