Worksheets for Yokogawa UT320/UT350 Temperature Control Program
for Pulse Modulating Boilers
Input/Output Menu
Symbol Description Default Value Fulton Value Customer Value
IN Input Type 1 4
UNIT Input Unit Selection C F
RH Range High Variable 210
RL Range Low Variable 0
SDP Scale Decimal Point 1 1
SH Scale High 100 0
SL Scale Low 0 0
RJC On/Off On On
BSL Burnout Selection 1 1
OT Output Type 0 2
RET Retransmission 1 1
RTH Retransmission High Variable 210
RTL Retransmission Low Variable 0
DIS Digital Input Off Off
C.S1 Custom Select Off Off
C.S2 Custom Select Off Off
C.S3 Custom Select Off Off
C.S4 Custom Select Off Off
LOCK Key Lock Off Off
PWD Password 0 0
Note: Parameters with bold values only will be used.
Functional Parameters
Symbol Description Default Value Fulton Value Customer Value
AL1 Alarm 1 Type 1 4
AL2 Alarm 2 Type 2 Off
AL3 Alarm 3 Type 3 Off
HY1 Alarm 1 Hysteresis 0.5 10
HY2 Alarm 2 Hysteresis 0.5 Off
HY3 Alarm 3 Hysteresis 0.5 Off
CT Control Output Type 30 1
CTc Control Output Type 30 Same
PO Preset Output 0 0
Poc Preset Output Cooling 0 0
C.MD PID Control 0 0
ZON Zone PID Control Off Off
AR Anti-Reset Windup Auto Auto
TMU Time Unit for Ramp 0 1
P.SL Protocol Selection 0 0
BPS Communication Speed 4 4
PRI Parity 1 1
STP Stop Bit 1 1
DLN Data Length 8 8
ADR Address 1 1
RP.T Minimum Response Time 0 0
TEST Test Control 0 0
Note: Parameters with bold values only will be used.
