Operating Parameters
Symbol Description Default Value Fulton Value Customer Value
AL1 Alarm 1 Setting 100 5
AL2 Alarm 2 Setting 0 0
AL3 Alarm 3 Setting 100 0
AT Auto-Tune Off Off
SC Super Function On/Off Off Off
SP.no Target Setpoint 1 1
PID PID Parameter 0
Enter 1 for PID
Menu then 0
FL PV Input Filter Off 0
BS PV Input Bias eus (0.0%) 0
UPR Rising Value Setting Off Off
DNR Descending Gradient Off Off
OH Output High Limit 100 100
OL Output Low Limit 0 0
H Hysteresis On/Off 0.10% 0.10%
DR Direct/Reverse Action 0 0
HB1 Heater Disconnect Off Off
HB2 Heater Disconnect Off Off
HC1 Heater Disconnect Off Off
HC2 Heater Disconnect Off Off
ORB On/Off Rate Detection eus (1.0%) 0
ORH On/Off Rate Upper Limit 100 100
ORL On/Off Rate Lower Limit 0 0
OR On/Off Rate 0 0
1.SP Target Setpoint 1 0 0
2.SP Target Setpoint 2 0 0
3.SP Target Setpoint 3 0 0
4.SP Target Setpoint 4 0 0
Note: Parameters with bold values only will be used.
PID Functions
Symbol Description Default Value Fulton Value Customer Value
1.P Proportional Band 5 10
1.I Integral 240 Off
1.d Derivative Off Off
1.MR Manual Reset 60 0
1.Pc Proportional Band 5 5
1.Ic Integral Time 240 240
1.Dc Derivative Time 60 60
1.DB Dead Band 3 3
1.RP Reference Point 1 100 100
2.RP Reference Point 2 100 100
RDV Reference Deviation 0.5 0.5
Note: Parameters with bold values only will be used.
