Worksheets for Siemens RWF40 Temperature Controller Standard Program
Display Paramete
r
V
endor
Setting
Fulton
Setting
Customer
Setting
Configuration Level
C111
analog input 1; analog input 2
a
; analog
input 3; setpoint changeover/shift
9030
D030 – Outdoor Sensor
D331
a
- 4-20mA external setpoint
with outside sensor
D431
a
- 0-10 VDC external
setpoint with outside sensor
C112
Limit comparator
b
; controller type; setpoint
1; locking
0010
0210 - standard program
C210
b
- “C” enables K6 relay used
for warm weather shutdown
C113
Instrument address; decimal place/unit,
signal for out-of-range
0010 0121
SCL Range start analog input 1
c
0 0
SCH Range end analog input 1
c
100
210 stainless steel
250 carbon steel
SCL2 Range start analog input 2
c
0 0
SCH2 Range end analog input 2
c
100
210 stainless steel
250 carbon steel
SPL Lower setpoint limit
c
0 0
SPH Upper setpoint limit
c
100
210 stainless steel
250 carbon steel
OFF1 Process value correction analog input 1
c
0 0
OFF2 Process value correction analog input 2
c
0 0
OFF3 Process value correction analog input 3
c
0 0
DF1
Filter time constant for digital filter, analog
input 1
1 0
DF3
Filter time constant for digital filter, analog
input 3
1 0
oLLo Lower working range limit -1999 0
OLHi Upper working range limit 9999
210 stainless steel
250 carbon steel
dtt Bus Watch Dog Timer 30 0
