FUNAI HDR-A2835D - Function Indicator Symbols

1-11-1 E434AFIS
FUNCTION INDICATOR SYMBOLS
< VCR Section >
Note:
If a mechanical malfunction occurs, the power is turned off. The following symbols will appear on the display.
When the power comes on again after that by pressing [STANDBY-ON] button, an error message is displayed on
the TV screen as follows.
When reel or capstan mechanism is not functioning
correctly
When tape loading mechanism is not functioning
correctly
When cassette loading mechanism is not functioning
correctly
When the drum is not working properly
P-ON+5V Power safety detection
Status Display
When reel or capstan mechanism is not
functioning correctly
“W” blinks.
When tape loading mechanism is not
functioning correctly
When cassette loading mechanism is not
functioning correctly
When the drum is not working properly
P-ON+5V Power safety detection
Fan does not rotate over 30 seconds.
“W” light and “R” blinks.
A
R
SP 0:00:00
Fig. 1
A
T
SP 0:00:00
Fig. 2
A
C
SP 0:00:00
Fig. 3
A
D
SP 0:00:00
Fig. 4
A
P
SP 0:00:00
Fig. 5
