FUNAI HDR-A2835D - Electrical Parts List

20061213 1-20-1 E434GEL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD MECHANISM & DVD/HDD MAIN
CBA ASSEMBLY
AV ASSEMBLY
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
HDR-A2835D A
HDR-B2735D B
Ref. No. Mark Description Part No.
1B2
1B2
A
B
DVD MECHANISM & DVD/HDD MAIN
CBA ASSEMBLY
DVD MECHANISM & DVD/HDD MAIN
CBA ASSEMBLY
N78GRBEN
N78GTBBN
Ref. No. Mark Description Part No.
A
B
AV ASSEMBLY
AV ASSEMBLY
Consists of the following:
1VSA14284
1VSA14956
AV CBA (AV PCB A)
POWER SW CBA (AV PCB B)
SENSOR CBA
----------
----------
1VSA13519
Ref. No. Mark Description Part No.
AV CBA (AV PCB A)
Consists of the following:
----------
CAPACITORS
C251 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C252 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C253 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C254 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C301 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C302 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C305 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C306 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C307 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C308 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C311 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C312 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C313 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C314 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C316 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C317 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C324 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C325 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C326 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C328 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
6.3V H7
CE0KMAVSM470
C329 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C331 ELECTROLYTIC CAP. 220µF/6.3V M H7
or
CE0KMAVSL221
ALUMINUM ELECTROLYTIC CAP
220µF/6.3V H7
CE0KMAVSM221
C332 ELECTROLYTIC CAP. 100µF/16V M H7 or CE1CMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/16V H7
CE1CMAVSM101
C333 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C334 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C335 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/6.3V H7
CE0KMAVSM101
C336 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C337 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
