FUNAI HDR-A2835D - Mechanical Parts List

20061213 1-19-1 E434GCA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
HDR-A2835D A
HDR-B2735D B
Ref. No. Mark Description Part No.
A-1X FRONT ASSEMBLY E434FED 1VM222690
A-2 MAIN CHASSIS E4340UD 1VM120193H
A-3 TOP COVER E4340UD 1VM020090F
A-4 REAR PANEL E434FED 1VM222697
A-5 FAN HOLDER E4340UD 1VM220745
A-7A FOOT E6500UD 0VM416122
A-7B FOOT E6500UD 0VM416122
A-9 A BARCODE LABEL E434GED ----------
A-9 B BARCODE LABEL E434JBD ----------
A-10 A RATING LABEL E434GED ----------
A-10 B RATING LABEL E434JBD ----------
A-11 CENTER CUSHION E4350JD 1VM422956
A-16 POWER HOLDER E434AED 1VM322233
A-22 TOPPER POP E434FED 1VM323234
A1X-1 FRONT PANEL E434FED 1VM222689
A1X-2 TRAY PANEL E434AED 1VM423384
A1X-3 POWER LENS E4340UD 1VM321075
A1X-4 VCR REC LENS E4340UD 1VM321076
A1X-5 DUBBING LENS E4340UD 1VM321077
A1X-6A MODE LENS E4340UD 1VM321078
A1X-6B MODE LENS E4340UD 1VM321078
A1X-6C MODE LENS E4340UD 1VM321078
A1X-7 HDD/DVD REC LENS E4340UD 1VM321079
A1X-8 DISPLAY WINDOW E434AED 1VM322197
A1X-9 CASSETTE DOOR E434AED 1VM423385
A1X-10 MODE BUTTON E434AED 1VM423386
A1X-11 POWER BUTTON E434AED 1VM423387
A1X-12 OPEN BUTTON E434AED 1VM423388
A1X-13 CENTER ORNAMENT E4340UD 1VM422053
A1X-14 ADHESIVE TAPE A E4340UD 1VM422054
A1X-15 ADHESIVE TAPE B E4340UD 1VM422055
A1X-16 TRAY SPRING E6510JD 0VM416265
A1X-17 DOOR SPRING HF410UD 1VM421240
A1X-18A FOOT E6500UD 0VM416122
A1X-18B FOOT E6500UD 0VM416122
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E1FL
1B3 ST3160212ACE ST3160212ACE or UHDD160VE002
HARD DISK DRIVE 160GB WD1600BB-
55RDA0 or
UHDD160WG002
HARD DISK DRIVE ST3160022ACE or UHDD160VE001
HARD DISK DRIVE WD1600BB-55GUC0 UHDD160WG001
B-1 HDD BRACKET E4340UD 1VM220719D
B-2 MODE LENS HOLDER E4340UD 1VM422056
B-3 WIRE SHEET E4340UD 1VM321081
B-4 TAPE HIMELON(HDD) E4340UD 1VM422058
B-7 EARTH PLATE E4321JD DV-HD300 0VM414677A
B-8 DECK PEDESTAL E9600UD 1VM120055D
B-11 FRONT BRACKET E9400UD 0VM204534C
B-12 FRONT BRACKET R E9400UD 0VM416269A
B-13 BRACKET R E9600UD 1VM421062F
B-14 TAPE HIMELON H9206JD 0VM413956
B-15 RUBBER CUSHION(TOP COVER)
E4340UD
1VM422515
B-18 FRONT SUPPORT E4340UD 1VM422518
B-19 SIDE CUSHION(TOP COVER) E4340UD 1VM422517
B-20 RUBBER CUSHION (MAIN CHASSIS)
E4340UD
1VM422534B
B-21 HDD SUPPORT E3A50JD 1VM424843
B-22A HDD RUBBER E4350JD 1VM422863
B-22B HDD RUBBER E4350JD 1VM422863
B-22C HDD RUBBER E4350JD 1VM422863
B-22D HDD RUBBER E4350JD 1VM422863
B-32 INSULATION SHEET E434AED 1VM424477
FM1001 DC FAN MOTOR 2410RL-04W-S20-C01
or
MMEZR12NM005
DC FAN MOTOR D06K-12TS7 01(AX) MMEZR12NH003
L-1A SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-1B SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-1C SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-1D SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-1E SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-1F SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-1G SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
L-3A SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-3B SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-3C SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
L-4A SCREW S-TIGHT M3*5 BIND+ 3*5
BIND+
GBHS3050
L-4B SCREW S-TIGHT M3*5 BIND+ 3*5
BIND+
GBHS3050
L-4C SCREW S-TIGHT M3*5 BIND+ 3*5
BIND+
GBHS3050
L-4D SCREW S-TIGHT M3*5 BIND+ 3*5
BIND+
GBHS3050
L-5A SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
L-5B SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
L-6A SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6B SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6C SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6D SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6E SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6F SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-6G SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
L-7A SCREW P-TIGHT M3*12 BIND+ GBJP3120
L-7B SCREW P-TIGHT M3*12 BIND+ GBJP3120
L-8A SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
L-8B SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
L-8C SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
L-9A SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9B SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9C SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9D SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9E SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9F SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9G SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9H SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9I SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9J SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9K SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9L SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9M SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9Q SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9R SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-10A SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L-10B SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
Ref. No. Mark Description Part No.
