FUNAI HDR-A2835D - Waveforms

WAVEFORMS
1-14-1
T2PWF
WF9
AUDIO(L)-OUT
Pin 17 of CN1504
1V 0.5ms
WF7
VIDEO-Cb
Pin 5 of CN1504
0.2V 20 µ s
WF8
VIDEO-Cr
Pin 3 of CN1504
0.2V 20 µ s
SPDIF 1V 0.1 µ s
WF10 Pin 30 of CN1501
WF4 Pin 7 of CN1504
VIDEO-Y 0.2V 20 µ s
WF5 Pin 9 of CN1504
VIDEO-C 0.2V 20 µ s
WF6 Pin 30 of IC1506
VIDEO-CVBS 0.5V 20 µ s
NOTE:
Input: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
WF3
WF1
UPPER
WF2
WF2
LOWER
TP504
UPPER
LOWER
TP504
TP301
V-OUT 0.5V
50
µs RF-SW 5V
C-PB
RF-SW 5V 5m
s
0.2V
WF1
Pin 56 of IC301
V-OUT E-E 0.2V 20 µs
Pin 56 of IC301
