20061213 1-20-7 E434GEL
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1536 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1539 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1540 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1541 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1542 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1543 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1544 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1545 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1546 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1550 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1551 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1552 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1553 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1554 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1555 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1556 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1557 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1606 ZENER DIODE MTZJT-778.2A or QDTA0MTZJ8R2
DIODE ZENER 8V2BSA-T26 or NDTA8R2BST26
ZENER DIODE DZ-8.2BSAT265 NDTA0DZ8R2BS
ICS
IC301 IC Y/C/A LA71750EM-MPB-E QSZBA0RSY020
IC451 IC HIFI LA72648M-MPB-E QSZBA0RSY033
IC501 SYSCON IC M3776AMCH-AE9GP QSZAC0RHT101
IC612 VFD DRIVER/CONTROLLER IC PT6313-
S-TP(L) or
NSZBA0TG2007
VFD DRIVER IC SC16313G NSZBA0T0S005
IC1501 IC OP AMP UTC4580 DIP-8 8PIN or NSZBA0S2H003
IC OP AMP RC4580IP NSZBA0STY173
If IC1502 is R3112N191A-TR-FA, R3112N191A-TR-FB or BU4221G-TR, then
C1549 is 0.015µF.
IC1502 VOLTAGE DETECT R3112N191A-TR-FA
or
QSZBA0TRC021
VOLTAGE DETECT R3112N191A-TR-FB
or
QSZBA0TRC022
RESET IC BU4219G-TR QSZBA0TRM090
C1549 CHIP CERAMIC CAP.(1608) B K 0.015µF/
50V
CHD1JK30B153
If IC1502 is PST3619NR, then C1549 is 0.1µF.
IC1502 SYSTEM RESET IC PST3619NR QSZBA0TMM151
Ref. No. Mark Description Part No.
C1549 CHIP CERAMIC CAP.(1608) B K 0.1µF/
50V
CHD1JK30B104
IC1503 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC1504 MICROCONTROLLER 8BIT MN101C77A
FL1
QSZAB0RMS052
IC1505 IC OP AMP KIA4558P/P or NSZBA0SJY035
IC OP AMP UTC4580 DIP-8 8PIN or NSZBA0S2H003
IC OP AMP RC4580IP NSZBA0STY173
IC1506 IC INTERFACE HA118326APF-E QSZBA0RHT051
COILS
L251 INDUCTOR 5.6µH-K-26T LLAXKATTU5R6
L302 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L402 INDUCTOR 47µH-K-5FT LLARKBSTU470
L451 INDUCTOR 47µH-K-5FT LLARKBSTU470
L452 PCB JUMPER D0.6-P5.0 JW5.0T
L501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L502 PCB JUMPER D0.6-P5.0 JW5.0T
L503 INDUCTOR 1.8µH-K-26T LLAXKATTU1R8
L1501 PCB JUMPER D0.6-P5.0 JW5.0T
L1503 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L1504 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L1505 INDUCTOR 100µH-K-5FT LLARKBSTU101
L1506 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1507 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1508 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L1509 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1510 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1511 PCB JUMPER D0.6-P5.0 JW5.0T
L1513 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1514 PCB JUMPER D0.6-P5.0 JW5.0T
L1516 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1601 BEAD CORE ASSEMBLY E9770ED 1VSA12652
TRANSISTORS
Q302 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q401 CHIP TRANSISTOR RN1511(TE85R.F)
or
QQ2Z0RN1511F
CHIP TRANSISTOR FMG4A T148 QQ2Z000FMG4A
Q402 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
Q403 TRANSISTOR KTC3203-Y-AT/P or NQSYKTC3203P
TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q404 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
Q405 RES. BUILT-IN TRANSISTOR KRA103M-
AT / P
NQSZ0KRA103M
Q406 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q451 TRANSISTOR KRC103S-RTK/P NQ1ZKRC103SP
Q506 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q514 TRANSISTOR KTA1267-Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q515 NPN TRANSISTOR KRC106M-AT/P or NQSZKRC106MP
NPN TRANSISTOR RES.-IN RN1206 QQSZ0RN1206F
Ref. No. Mark Description Part No.
