20061213 1-20-16 E434GEL
SWITCHING DIODE KDS160E-RTK/P ND1ZKDS160EP
ICS
IC1001
!
PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
IC1101 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC1102 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC1103 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC1104 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
COILS
L1001 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1002 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1003! COIL LINE FILTER 56MH
TLF24HB5630R3 or
LLEG0Z0TU001
! COIL LINE FILTER 68MH HF2430-
683Y0R4-T01
LLBG00ZTE027
L1004 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1005 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1013 POWER INDUCTORS TWKBNP-220K or LLC220KKV007
CHOKE COIL(22µH) LHL10NB220K or LLARKGQTU220
POWER INDUCTORS CWKBNP-220K LLF2200KV002
L1014 RADIAL LEADED INDUCTOR
LHL13NB100K or
LLC100KTU026
POWER INDUCTORS CWKBNP-100K LLF1000KV002
L1100 POWER INDUCTORS TWKBNP-180K or LLC180KKV007
CHOKE COIL(18µH) LHL10NB180K or LLARKGQTU180
POWER INDUCTORS CWKBNP-180K LLF1800KV002
L1101 POWER INDUCTORS TWKBNP-180K or LLC180KKV007
CHOKE COIL(18µH) LHL10NB180K or LLARKGQTU180
POWER INDUCTORS CWKBNP-180K LLF1800KV002
TRANSISTORS
Q1001! MOS FET 2SK3798(Q) QFWZ2SK3798Q
Q1003 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1100 TRANSISTOR(PB FREE) KTC2026-Y/P NQEYKTC2026P
Q1101 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
Q1102 TRANSISTOR S2Y52(FUNAI Q H) QQWZ00S2Y52Q
Q1103 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q1104 TRANSISTOR KTC3203-Y-AT/P or NQSYKTC3203P
TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1105 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q1106 TRANSISTOR KTC3266-Y-AT/P or NQSYKTC3266P
TRANSISTOR KTC3266-GR-AT/P or NQS4KTC3266P
TRANSISTOR 2SC3266-Y(TPE2 F) or QQSY2SC3266F
TRANSISTOR 2SC3266-GR(TPE2 F) QQS12SC3266F
Q1107 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
Q1108 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
Q1109 TRANSISTOR(PB FREE) KTC2026-Y/P NQEYKTC2026P
Q1110 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q1111 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
Q1114 TRANSISTOR KTA1267-Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1115 NPN TRANSISTOR KRC103M-AT/P NQSZKRC103MP
RESISOTRS
R068 CARBON RES. 1/6W J 22k Ω or RCX6JATZ0223
CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
Ref. No. Mark Description Part No.
R1003 CEMENT RESISTOR 3W K 1.5 Ω or RW031R5PAK10
CEMENT RES 3W K 1.5 Ω RW031R5PG007
R1004 CEMENT RESISTOR 5W J 1.0 Ω H
10MM or
RW051R0PAK10
CEMENT RES. 5W K 1.0 Ω RW051R0DP005
R1005 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1006 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684
R1007 CARBON RES. 1/4W J 680k Ω RCX4JATZ0684
R1008 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824
R1009 CARBON RES. 1/4W J 22 Ω RCX4JATZ0220
R1029 CARBON RES. 1/4W J 180k Ω RCX4JATZ0184
R1033 CARBON RES. 1/4W J 56 Ω RCX4JATZ0560
R1034 PCB JUMPER D0.6-P5.0 JW5.0T
R1035 PCB JUMPER D0.6-P5.0 JW5.0T
R1036 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1037 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1039 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R1043 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1100 CHIP RES. 1/10W J 390 Ω or RRXAJR5Z0391
RES CHIP 1608 1/10W J 390 Ω RRXA391YF002
R1101 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1102 CHIP RES. 1/10W F 2k Ω or RRXAFR5H2001
CHIP RES. 1/10W F 2k Ω or RRXAFR5Z2001
RES CHIP 1608 1/10W F 2.00k Ω RTW2001YF002
R1104 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1106 CHIP RES.(1608) 1/10W J 0.47 Ω or RRXAR47HH007
CHIP RES.(1608) RLC16KR470J RRX8R47KE001
R1107 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1108 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1110 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1111 PCB JUMPER D0.6-P5.0 JW5.0T
R1112 CHIP RES. 1/10W F 300 Ω or RRXAFR5H3000
CHIP RES.(1608) 1/10W F 300 Ω or RRXAFR5Z3000
RES CHIP 1608 1/10W F 300 Ω RTW3000YF002
R1113 CHIP RES. 1/10W F 1.0k Ω or RRXAFR5H1001
CHIP RES. 1/10W F 1k Ω or RRXAFR5Z1001
RES CHIP 1608 1/10W F 1.00k Ω RTW1001YF002
R1114 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1115 CHIP RES. 1/10W F 1.0k Ω or RRXAFR5H1001
CHIP RES. 1/10W F 1k Ω or RRXAFR5Z1001
RES CHIP 1608 1/10W F 1.00k Ω RTW1001YF002
R1117 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1118 METAL OXIDE FILM RES. 3W J 1.0k Ω or RN03102ZU001
METAL OXIDE FILM RES. 3W J 1k Ω RN03102KE009
R1119 CHIP RES. 1/10W J 220k Ω or RRXAJR5Z0224
RES CHIP 1608 1/10W J 220k Ω RRXA224YF002
R1120 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1123 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1124 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1125 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1126 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1127 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1128 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R1129 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1130 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1131 CHIP RES. 1/10W J 18k Ω or RRXAJR5Z0183
RES CHIP 1608 1/10W J 18k Ω RRXA183YF002
R1132 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1133 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
Ref. No. Mark Description Part No.
