FUNAI HDR-A2835D - Page 93

20061213 1-20-20 E434GEL
ATA CBA
R5 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
Ref. No. Mark Description Part No.
ATA CBA
Consists of the following:
1VSA13582
CONNECTORS
CN3001 IDC SOCKET 40PIN VT YKF43-0025 JCYKC40JC002
CN3001 RECEPTACLE 40PIN HIF3FB-40DA-
2.54DSA(
JCFBC40HQ003
CN3002 FPC/FFC CONNECTOR(40PIN) FH12-
40S-0.5SH(89)
JCFHD40HQ007
Ref. No. Mark Description Part No.
