FUNAI LC5-D32BB - Mechanical Parts List

20071107 12-1 A73F0CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A73F0EP 1EM021797A
A2 BRAND BADGE L5825FF 1EM424293
A3 CONTROL PLATE A73F0EP 1EM322721
A4 REAR CABINET A73F0EP 1EM021798B
A5 DECORATION PLATE A73F0EP 1EM121952
A7 FUNCTION KNOB A73F0EP 1EM121950
A9 STAND COVER L4301UB 1EM221344B
A10 REAR COVER A73F0EP 1EM322722
A12 STAND RUBBER FOOT L5001CB 1EM423855
A14 JACK PLATE A73F0EP 1EM221631
B1 PANEL HOLDER 32V A71F0UH 1EM121831A
B3 SHIELD BOX A74F0UH 1EM121927
B4 CHASSIS BRACKET 32V A71F0UH 1EM121806A
B5 JACK HOLDER(A) A73F0EP 1EM221630
B6 JACK HOLDER(D) A73F0EP 1EM221629
B7 STAND BASE PLATE L4300UA 1EM121113B
B8 STAND HINGE A71F3UH 1EM221883
B16 CLOTH(10X180XT0.5) L0336JG 0EM408827
B17 CLOTH 10X150XT1.0 1EM421092
B19 CLOTH(20X65XT0.5) L0100JA 0EM407914
B29 SHIELD PLATE A73F0EP 1EM221633
B30 SHIELD PLATE(B) A73F0EP 1EM425060
B39 GASKET(A) A73F0EP 1EM424765
B40 GASKET(B) A73F0EP 1EM425059
CL3302 WIRE ASSEMBLY LVDS-FFC 30PIN / 30MM /
UL289
WX1A73F0-101
CL7001 WIRE ASSEMBLY FFC 39PIN / 130MM / UL28 WX1A73F0-102
CLN102 WIRE ASSEMBLY 002 6PIN / 185MM / AWG26 WX1A71F3-002
CLN801 WIRE ASSEMBLY 2PIN/280MM/UL1007 WX1A73F0-006
CLN802 WIRE ASSEMBLY 2PIN/280MM/UL1007 WX1A73F0-006
L3 SCREW P-TIGHT M3X12 DISH HEAD+ GDJP3120
L4 SCREW P-TIGHT M3X10 BIND HEAD+ GBJP3100
L7 SCREW B-TIGHT 3X10 BIND HEAD+ BLK GBHB3100
L9 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L12 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
SP801 SPEAKER S0516F06 DSD0813XQ002
SP802 SPEAKER S0516F06 DSD0813XQ002
ACCESSORY
X3 REMOTE CONTROL NF021RD NF021RD NF021RD
Ref. No. Description Part No.
A6! RATING LABEL A73F0EP ----------
B20 GASKET A71F0UH 1EM424393
B34 RUBBER CUSHION (10X10X20) A71F0UH 1EM424528
B41 RUBBER CUSHION (10X10X13) A71F0UH 1EM424527
L1 SCREW P-TIGHT 4X14 BIND HEAD GBJP4140
L2 SCREW P-TIGHT M4X14 PAN HEAD+BLK GPHP4140
L4 SCREW P-TIGHT M3X10 BIND HEAD+ GBJP3100
L7 SCREW B-TIGHT 3X10 BIND HEAD+ BLK GBHB3100
L9 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L11 DOUBLE SEMS SCREW M4X6 M4X6 FPJ34060
L12 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
L18 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L19 HEX SCREW #4-40 7MM 1EM422042
PACKING
S1 CARON A73F0EP 1EM322938
S2 STYROFOAM TOP A73F0EP 1EM021811
S3 STYROFOAM BOTTOM A73F0EP 1EM021812
S4 SET BAG L5820EA 1EM322297
S5 SERIAL NO. LABEL L9750UA ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2-1! OWNERS MANUAL(EN) A73F0EP 1EMN22287
X2-2! OWNERS MANUAL(FR) A73F0EP 1EMN22288
X2-3! OWNERS MANUAL(DE) A73F0EP 1EMN22289
X2-4! OWNERS MANUAL(IT) A73F0EP 1EMN22290
X2-5! OWNERS MANUAL(ES) A73F0EP 1EMN22291
X2-6! OWNERS MANUAL(NL) A73F0EP 1EMN22292
X2-7! OWNERS MANUAL(SV) A73F0EP 1EMN22293
X2-8! OWNERS MANUAL(RU) A73F0EP 1EMN22294
X2-9! OWNERS MANUAL(PL) A73F0EP 1EMN22295
X2-10! OWNERS MANUAL(HU) A73F0EP 1EMN22296
X2-11! OWNERS MANUAL(CS) A73F0EP 1EMN22297
X2-12! OWNERS MANUAL(EL) A73F0EP 1EMN22298
X2-13! OWNERS MANUAL(SK) A73F0EP 1EMN22302
X2-14! OWNERS MANUAL(AR) A73F0EP 1EMN22303
X2-15! OWNERS MANUAL(PT) A73F0EP 1EMN22304
X2-16! OWNERS MANUAL(RO) A73F0EP 1EMN22305
X2-17! OWNERS MANUAL(BG) A73F0EP 1EMN22306
X5 BATTERY R6RC/2P XB0M601MS001
