20071107 13-1 A73F0EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
LCD MODULE ASSEMBLY
*Flicker Adjustment and White Balance Adjustment
are required when reparing T-CON CBA.
DIGITAL MAIN CBA UNIT
MMA CBA
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
LCD MODULE ASSEMBLY
Consists of the following:
UF320EA
T-CON CBA
CELL ACF ASSEMBLY
BACKLIGHT ASSEMBLY
1FSA10301
----------
----------
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT 1ESA14674
Ref. No. Description Part No.
MMA CBA
Consists of the following:
1ESA14670
POWER SUPPLY CBA
FUNCTION CBA
IR SENSOR CBA
----------
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists of the following:
----------
CAPACITORS
C601! ALUMINUM ELECTROLYTIC CAP 180µF/400V
M
CA2H181NC206
C602 CERAMIC CAP. BN 680pF/2KV or CCD3DKA0B681
CERAMIC CAP. 680pF/2KV or CA3D681PAN04
CERAMIC CAP. RB 680pF/2KV or CA3D681TE006
CERAMIC CAP. BL 680pF/2KV CA3D681XF003
C604 FILM CAP.(P) 0.082µF/50V J or CMA1JJS00823
POLYESTER FILM CAP. (PB FREE) 0.082µF/
100V J
CA2A823DT018
CAP POLYESTER FILM 0.082µF/50V J CA1J823SER04
C605 CERAMIC CAP.(AX) B K 0.01µF/50V CA1J103TU011
C606 FILM CAP.(P) 0.1µF/50V J or CA1J104MS029
FILM CAP.(P) 0.1µF/50V J or CMA1JJS00104
CAP POLYESTER FILM 0.1µF/50V J CA1J104SER04
C607! SAFTY CAP. 1000pF/250V KX CA2E102MR101
C631 CERAMIC CAP. F Z 0.01µF/500V or CCD2JZP0F103
CERAMIC CAP. E Z 0.01µF/500V CCD2JZP0E103
C633 ALUMINUM ELECTROLYTIC CAP 1000µF/25V
M or
CE1EMZNTM102
ELECTROLYTIC CAP. 1000µF/25V M or CA1E102SP084
ELECTROLYTIC CAP. 1000µF/25V M or CE1EMZNDL102
ELECTROLYTIC CAP. 1000µF/25V M CE1EMZPDL102
C634 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 or CE1AMZNDL472
ELECTROLYTIC CAP. 4700µF/10V M CE1AMZPDL472
C635 FILM CAP.(P) 0.01µF/50V J or CA1J103MS029
FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
POLYESTER FILM CAP. (PB FREE) 0.01µF/
100V J
CA2A103DT018
C638 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 or CE1AMZNDL472
ELECTROLYTIC CAP. 4700µF/10V M CE1AMZPDL472
C639 ELECTROLYTIC CAP 470µF/50V M CE1JMZADL471
C640 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220
ELECTROLYTIC CAP. 22µF/16V M or CA1C220SP085
ALUMINUM ELECTROLYTIC CAP 22µF/16V M CE1CMASTM220
C642 CAP ELE STD-85 4700µF 6.3V SL or CE0KMZNDL472
ELECTROLYTIC CAP. 4700µF/6.3V SM CE0KMZPDL472
C643 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 or CE1AMZNDL472
ELECTROLYTIC CAP. 4700µF/10V M CE1AMZPDL472
C644 ELECTROLYTIC CAP. 1000µF/16V M or CE1CMASTL102
ELECTROLYTIC CAP. 1000µF/16V M CE1CMASDL102
C647 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C648 ALUMINUM ELECTROLYTIC CAP 1000µF/25V
M or
CE1EMZNTM102
ELECTROLYTIC CAP. 1000µF/25V M or CA1E102SP084
ELECTROLYTIC CAP. 1000µF/25V M or CE1EMZNDL102
ELECTROLYTIC CAP. 1000µF/25V M CE1EMZPDL102
C649 ELECTROLYTIC CAP. 220µF/25V M or CE1EMASDL221
ELECTROLYTIC CAP. 220µF/25V M or CA1E221SP085
ELECTROLYTIC CAP. 220µF/25V M CE1EMASTM221
C650 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C651 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C652 ELECTROLYTIC CAP. 100µF/10V M or CA1A101SP085
ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101
C653 ELECTROLYTIC CAP. 100µF/10V M or CA1A101SP085
ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101
C654 ELECTROLYTIC CAP. 4700µF/10V M P=7.5 or CE1AMZNDL472
ELECTROLYTIC CAP. 4700µF/10V M CE1AMZPDL472
C655 ELECTROLYTIC CAP. 1000µF/10V M or CE1AMASDL102
ELECTROLYTIC CAP. 1000µF/10V M or CA1A102SP085
ALUMINUM ELECTROLYTIC CAP 1000µF/10V
M
CE1AMASTM102
C656 CAP ELE STD-85 4700µF 6.3V SL or CE0KMZNDL472
ELECTROLYTIC CAP. 4700µF/6.3V SM CE0KMZPDL472
C657 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C658 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C659 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C660 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C661 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C662 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C663 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C665 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C669 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C801 ELECTROLYTIC CAP. 100µF/16V M or CA1C101SP085
ELECTROLYTIC CAP. 100µF/16V M or CE1CMASTM101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C802 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C803 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C804 ELECTROLYTIC CAP. 100µF/16V M or CA1C101SP085
Ref. No. Description Part No.
