FUNAI LC5-D32BB - Page 60

20071107 13-2 A73F0EL
ELECTROLYTIC CAP. 100µF/16V M or CE1CMASTM101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C805 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C806 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C807 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C808 ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASDL3R3
C809 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C810 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C811 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C812 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C813 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C814 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C815 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C816 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C817 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C818 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C819 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M or CA1J1R0SP085
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C821 PCB JUMPER D0.6-P5.0 JW5.0T
C822 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C823 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C824 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C825 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C826 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C827 PCB JUMPER D0.6-P5.0 JW5.0T
C833 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C834 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C835 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C842 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C843 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C851 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C853 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C854 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C857 ELECTROLYTIC CAP. 100µF/16V M or CA1C101SP085
ELECTROLYTIC CAP. 100µF/16V M or CE1CMASTM101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C859 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470
C860 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C861 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C862 ELECTROLYTIC CAP. 4.7µF/16V M or CE1CMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CA1E4R7SP085
ALUMINUM ELECTROLYTIC CAP 4.7µF/25V M CE1EMASTM4R7
C863 ELECTROLYTIC CAP. 4.7µF/16V M or CE1CMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CA1E4R7SP085
ALUMINUM ELECTROLYTIC CAP 4.7µF/25V M CE1EMASTM4R7
C864 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C865 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C866 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C867 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C868 CHIP CERAMIC CAP.(1608) B K 2700pF/50V CHD1JK30B272
C869 CHIP CERAMIC CAP.(1608) B K 2700pF/50V CHD1JK30B272
C870 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C871 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C872 CHIP CERAMIC CAP. F Z 0.068µF/50V CHD1JZ30F683
C873 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C875 ELECTROLYTIC CAP. 4.7µF/16V M or CE1CMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CA1E4R7SP085
ALUMINUM ELECTROLYTIC CAP 4.7µF/25V M CE1EMASTM4R7
C876 ELECTROLYTIC CAP. 4.7µF/16V M or CE1CMASDL4R7
Ref. No. Description Part No.
ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7
ELECTROLYTIC CAP. 4.7µF/25V M or CA1E4R7SP085
ALUMINUM ELECTROLYTIC CAP 4.7µF/25V M CE1EMASTM4R7
C877 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C878 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C880 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C883 CERAMIC CAP.(AX) B K 0.1µF/25V CCA1EKT0B104
C1602 ALUMINUM ELECTROLYTIC CAP 1000µF/35V
M or
CE1GMZNTM102
ELECTROLYTIC CAP. 1000µF/35V M or CA1G102SP084
ELECTROLYTIC CAP. 1000µF/35V M or CE1GMZADL102
ELECTROLYTIC CAP. 1000µF/35V M CE1GMZPDL102
C1603 CERAMIC CAP.(AX) B K 0.01µF/50V CA1J103TU011
CONNECTORS
CN301 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN302 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN303 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN601 WIRE ASSEMBLY 2PIN/120MM/UL1672 WX1A73F0-007
CN701 CONNECTOR PRINT MES 39FMN-BTK-
A(LF)(SN)
JCFNG39JG019
DIODES
D602! ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D603 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D604! ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D605 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D606 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D607 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D608 DIODE TRANSIENT VOLTAGE SUPPRE
P6KE250ABE
NDLZP6KE250A
D609 DIODE FAST RECOVERY FR157 NDLZ000FR157
D611 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D612 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D613 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D631 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D632 SCHOTTKY BARRIER DIODE ERC81-004 or QDPZERC81004
SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D633 RECTIFIER DIODE FR202-B/P or NDQZ000FR202
FAST RECOVERY DIODE FR202 NDWZ000FR202
D635 ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D636 RECTIFIER DIODE FR203-B/P NDQZ000FR203
D637 SCHOTTKY BARRIER DIODE ERC81-004 or QDPZERC81004
SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D640 SCHOTTKY BARRIER DIODE ERC81-004 or QDPZERC81004
SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D641 SCHOTTKY BARRIER DIODE ERC81-004 or QDPZERC81004
SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D642 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D643 ZENER DIODE MTZJT-7712B QDTB00MTZJ12
D644 DIODE 1ZC43(Q) or QDLZ001ZC43Q
DIODE ZENER RD43F-T7-AZ-B QDJB0RD43FAZ
D646 ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D649 ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D650 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D651 SCHOTTKY BARRIER DIODE ERA81-004Q or QDLZRA81004Q
SCHOTTKY BARRIEA DIODE 11EQS04 or QD4Z011EQS04
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D652 PCB JUMPER D0.6-P5.0 JW5.0T
D654 SCHOTTKY BARRIER DIODE ERA81-004Q or QDLZRA81004Q
SCHOTTKY BARRIEA DIODE 11EQS04 or QD4Z011EQS04
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D655 DIODE FR104-B or NDLZ000FR104
RECTIFIER DIODE ERA22-02 or QDPZ0ERA2202
RECTIFIER DIODE 10ELS2 or QDQZ0010ELS2
DIODE 10ERB20 or QDLZ010ERB20
Ref. No. Description Part No.
