TYPE G
PARTS LIST [LF320EM4 A(Serial No.: ME8)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Different parts from the original model
LF320EM4 A (Serial No. : DS1)
Ref.No. Description Parts No.
A3 REAR COVER A4AFSUT 2EMM00677
A15# RATING LABEL A4AFSUT ----------
A16 LOGO LABEL A3AF0UT ----------
A17 ENERGY GUIDE LABEL A4AFSUT ----------
B2-1 CLOTH(10X180XT0.5) A01FKUT 1EM432497
B2-2 Not used
B5 PCB HOLDER A4AF0UH 2EMS00098A
SA1 STAND ASSEMBLY A31M0UT 1ESA34014
SP3801 SPEAKER MAGNETIC S065F44 DS08060XQ003
SP3802 SPEAKER MAGNETIC S065F44 DS08060XQ003
SSK1 STAND SCREW KIT A31M0UT(SCREW BIND
BLACK_NI +P-TITE M4X14.0)
1ESA34004
PAC K IN G
S1 CARTON A4AFSUT 2EMC00783
S6 SET BAG A31F0UT 2EMC00088A
S7 SERIAL NO. LABEL A4GF1UT ----------
ACCESSORIES
X2# OWNERS MANUAL A4AFBUT 2EMN00189
X3 REMOCON UNIT NH310UP NH310UP
X6 QUICK START GUIDE A4AFBUT 2EMN00190
LCD1# LCD PANEL ASSEMBLY U44FDRA
A1 FRONT CABINET A4AFSUT 2EMM00711
B2-1 CLOTH(10X180XT0.5) A01FKUT 1EM432497
CL3102 FFC WIRE ASSEMBLY 24PIN 24PIN/WHITE/
50MM
WX1A4AFPS101
