EVO EXPERT Manual 9/105
Fig. 3 Back view of the equipment
1. Power switch
2. Power cable slot
3. Warning Label
4. Serial number label
5. USB Connector
6. USB Temperature probe
connector
7. Level
Fig. 4. Equipment identification label
Description of the equipment identification label:
1. Viscometer model
2. Viscometer code
3. Electronic equipment (specifies throw in trash)
4. Serial number of the equipment
5. Voltage and power of the equipment
7.1 Equipment set-up
 Remove all of the parts from the carry-case. Note the figure below (fig 5).
 Correctly place the three height adjustable knobs (B) on the Y-shaped base (A).
1
1
2
3
4
5
2
3
4
5
6
7
