Furuno 1722C - Appendix; Menu Overview

A
P-1
APPENDIX
Menu Overview
MENU key
Radar
nm & sm range
(0.125/0.25/0.5/0.75/1/1.5/2/3/4/6/8/12/16/24/36/48/64)
km range
(0.25/0.5/0.75/1/1.5/2/3/4/6/8/12/16/24/36/48/64)
MENU Key
EBL REFERENCE (TRUE, RELATIVE)
CURSOR POSITION (LAT/LON, TD, RNG&BRG-REL, RNG&BRG-TRU)
TUNING (AUTO, MAN)
TX SECTOR BLANKING (ON (FROM SECTOR), OFF)
NOISE REJECTION (OFF, LOW, HIGH)
BACKGROUND COLOR (BLACK/GREEN, BLACK/RED, BLUE/WHITE,
DK BLUE/WHITE, WHITE/GREEN)*
ECHO COLOR (YELLOW, GREEN, MULTI-COLOR)*
WATCHMAN TIME (5, 10, 20 minutes)
RANGE UNIT (nm, km, sm)
DATA BOX soft key (Same items as on plotter menu.)
SOFTKEY 1 - SOFTKEY 5
(OFF, HDG LINE OFF, MODE, GAIN, A/C SEA, A/C RAIN, FTC,
ECHO STRETCH, PULSE LENGTH, ZOOM, OFFCENTER, ECHO
TRAIL, RINGS ON/OFF, TLL OUTPUT, GUARD ALARM, EBL, VRM,
TTM ON/OFF, WPT ON/OFF, WATCHMAN, ACQUISITION, STBY/TX,
RADAR SOURCE, DATA BOX ON/OFF, CHANGE CNTRL
Assigns function of each radar function key.)
RADAR
DISPLAY
SETUP
RADAR
RANGE
SETUP
ARP SETUP
FUNCTION
KEY SETUP*
SYSTEM CONFIGURATION (See page AP-6.)
ARP TARGET INFO (INTERNAL ARPA, EXTERNAL ARP, OFF)
CANCEL ALL TARGETS (YES, NO)
ARP VECTOR MODE (RELATIVE, TRUE)
ARP VECTOR TIME (30seconds, 1, 3, 6, 15, 30minutes)
HISTORY INTERVAL (OFF, 30sec; 1, 3, 6 minutes)
CPA (OFF, 0.5, 1, 2, 3, 5, 6nm)
TCPA (30seconds, 1, 2, 3, 4, 5, 6, 12minutes)
AUTO ACQUISITION AREA (ON, OFF)
TARGET ID NUMBER (ON, OFF)
* = MODEL1722C
series only.
(Requires ARP
circuit board in
network radar
1833/1833C
series.)
* Default settings for function keys:
SOFTKEY 1, HDG LINE OFF; SOFTKEY 2, RANGE; SOFTKEY 3, ECHO TRAIL;
SOFTKEY 4, OFFCENTER, SOFTKEY 5, RADAR SOURCE
