1. OPERATIONAL OVERVIEW
1-15
1.6 Sonar Menu Overview
This equipment has four menus: sonar menu, sounder menu, marks menu and
system menu. Of the four menus, the SONAR menu is the one you will use most
often.
Note that the gain and range cannot be adjusted while the menu is displayed.
1.6.1 Operating procedure
1. Press the [MENU] key. The last-used menu appears.
2. Use the [RANGE] control to choose [MENU MODE] at the top of the screen.
3. Use the [GAIN] control to choose SONAR to display the SONAR menu.
**
SONAR MENU
**
(RANGE CTRL: U/D, GAIN CTRL: L/R)
[MENU MODE] : SONAR SOUNDER MARKS SYSTEM
DISPLAY MODE : COMBI-1 NORM COMBI-2
TX OUTPUT : 8
PULSE LENGTH : 8
TX CYCLE : 10
TVG NEAR : 6
TVG FAR : 7
AGC : 2
2ND AGC : 1
NOISE LIMITER : 3
COLOR CURVE : 1 2 3 4
COLOR RESPONSE
:1 2 3 4
DELETE COLOR : 0
ECHO AVERAGE : 1
INT REJECT : 1
HOR BEAMWIDTH : WIDE NARROW
VER BEAMWIDTH : WIDE NARROW
COLOR : 1 234
ERASE MARKS : TRACK SHIP EVENT FISH
ALARM LEVEL : 9
AUTO TRAIN : ON OFF
TRAIN SECTOR :
±
10
° ±
20
°±
40
° ±
60
°
AUTO TILT : ON OFF
TILT ANGLE :
±
2-10
° ±
4-14
°±
6-20
° ±
10-26
°
TRANSMISSION : ON OFF
AUDIO VOLUME : 10
ASSIGN SETTING : F1 KEY F2 KEY F3 KEY F4 KEY
ASSIGN MENU : EXECUTE
PRESS [MENU] KEY TO EXIT
Sonar menu
