7. MARKS AND SYSTEM MENUS
This chapter describes the MARKS and SYSTEM menus. To display the
SYSTEM or MARKS menu, do the following:
1. Press the [MENU] key to open the menu.
2. Use the [RANGE] control to [MENU MODE] at the top of the screen.
3. Use the [GAIN] control to choose SYSTEM or MARKS as appropriate.
7.1 MARKS Menu
**
MARKS MENU
**
(RANGE CTRL: U/D, GAIN CTRL: L/R)
[MENU MODE] : SONAR SOUNDER MARKS SYSTEM
RANGE RINGS : 1/4R 1/2R OFF
BEARING SCALE : ON OFF
CURRENT VECTOR
: ON OFF
CURRENT DIR : TO FROM
SHIP’S TRACK : 10R 5R OFF
COURSE : 32CMPS 360TRUE
HEADING : 32CMPS 360TRUE OFF
CURRENT DATA : 32CMPS 360TRUE
±
180
°
360
°
EVENT/FISH : 32CMPS 360TRUE
±
180
°
360
°
OTHER MARKS :
±
180
°
360
°
POSITION DATA : L/L TD
PRESS [MENU] KEY TO EXIT
MARKS menu
