SYSTEM CONFIGURATION
Processor Unit
CSH-5210
Transceiver Unit
CSH-5130
Control Unit
CSH-5211
Pre-amplifier Unit
CSH-5020
Hull Unit
CSH-5040, 600 mm stroke
CSH-5041, 400 mm stroke
Ship's Mains
100 VAC/
115 VAC/
200 VAC/
220 VAC/
240 VAC,
1
f
, 50-60Hz
DC/AC
Inverter
TR-2451
24 VDC
Motion Sensor
MS-100
Navaid
Current Indicator
AD Converter
Speed Log
E/S Interface
Remote Controller
Speaker
Monitor (MU-150C, etc., Max. 2)
: Standard Supply
: Option
: User Supply
System configuration of CSH-5L
