4. INSTALLATION
26
Combination of transducer, thru-hull pipe and tank
Output
(W)
Frequency
(kHz)
Ship type Transducer Thru-hull pipe Tank
1k/1k 50/200 Steel 50/200-1T TFB-5000(1) T-603
FRP – T-603F
1k/2k 50/200 Steel 50B-9B
200B-8/8B
TWB-6000(2) T-658
FRP
2k/2k 50/200 Steel 50BL-12HR
200B-8/8B
TFB-7000(2) T-693
FRP TRB-1100(2) T-693-F
3k/3k 50/200 Steel 50BL-24HR
200B-12H
TFB-7000(2) T-683
FRP TRB-1100(2) T-683-F
1k 50 Steel 50B-6/6B TFB-5000(1) T-605
FRP TRB-1000(1) T-605-F
Steel 50B-9B TFB-5000(1) T-603
FRP TRB-1000(1) T-603-F
200 Steel 200B-5S TFB-5000(1) T605
FRP TRB-1000(1) T-605-F
2k 50 Steel 50BL-12HR TFB-5000(1) T-702
FRP TRB-1000(1) T-702-F
200 Steel 200B-8/8B TFB-5000(1) T-608
FRP TRB-1000(1) T-608-F
3k 50 Steel 50BL-24HR TFB-4000(1) T-616
FRP TRB-1000(1) T-616-F
200 Steel 200B-12H TFB-5000(1) T-615
FRP TRB-1000(1) T615-F
