4. INSTALLATION
4.1 Equipment Lists
Standard supply
Option
Name Type Code No. Qty Remarks
Display Unit CV-288 – 1
Installation Materials 1 set See packing list at back of this man-
ual.
Spare Parts 1 set
Name Type Code No. Remarks
Transducer See next page –
Thru-hull pipe –
Tank –
Hard Cover 02-160-1091-2 For Display Unit
Cable MJ-A6SPF0003-050C 000-154-054-10 One end 6 pin, 5 m, for navigator
CO-SPEVV-SB-C
2Px0.2 LF
000-111-680-10 5 m
000-120-792-10 10 m
000-120-793-10 15 m
Water temperature
sensor
T42 000-026-893 Thru-hull type
T80 000-026-894 Transom type
Speed/Tempera-
ture sensor
ST-02MSB 000-137-986-01 Thru-hull type
ST-02PSB 000-137-987-01 Thru-hull type
Rectifier PR-62 000-013-484 100 VAC
000-013-485 110 VAC
000-013-486 220 VAC
000-013-487 230 VAC
Strain Relief Plate OP02-85 001-188-530 For WAGO connectors
