2. CONNECTIONS
29
3. With the connector cover rail in the slot, raise the connector cover in the direction of the arrow
as shown below.
4. Push the connector cover in towards the triangle mark on the center top of the Communication
Unit to affix.
Raise
As seen from above
(push in towards mark
䋩
Triangle
Triangle mark
Grommets (4)
Connector cover
Cable fixture
