AP-17
APPENDIX 5 ALERT LIST
This radar outputs alert information in ALR format. When the alert status changes from OFF (no
alert) to ON (error), an alert pop-up appears and the audio alarm sounds.
• The alert pop-up can be erased and the audio alarm silenced by pressing any key.
• The alert pop-up and the audio alarm are generated whenever an alarm condition occurs or re-
occurs. This condition continues until all the causes for an alert are removed or the alert(s) are
acknowledged.
• When multiple alerts are generated simultaneously, and there is no alert acknowledgement, the
audio alarm continues to sound no matter even if an alert condition has gone. Also, the pop-up
remains displayed and the latest alert appears in the pop-up
• When there is no alert acknowledgment, the audio alarm continues until the condition causing
the alert(s) is removed. The pop-up remains displayed.
• When multiple alerts are generated simultaneously, press any key to acknowledge all alerts.
• To indicate that multiple alerts have been generated simultaneously, the pop-up shows “(!)”after
the alert name, as in the example below.
SIGNAL MISSING ALERTS
This radar releases an audiovisual alarm against missing signals.
• [SIGNAL MISSING] TRIGGER
The trigger signal from the antenna unit is missing.
• [SIGNAL MISSING] HEADING
The heading signal from the antenna unit is missing.
• [SIGNAL MISSING] BEARING
The bearing signal from the antenna unit is missing.
• [SIGNAL MISSING] VIDEO
The video signal from the antenna unit is missing.
• [SIGNAL MISSING] ANT ERR
No communication with antenna unit for one minute.
[SIGNAL MISSING] [107] POSITION (!)
[SIGNAL MISSING] [101] TRIGGER
[SIGNAL MISSING] [102] HEADING
[SIGNAL MISSING] [103] BEARING
[SIGNAL MISSING] [104] VIDEO
[SIGNAL MISSING] [105] ANT ERR
