3.11.8 Alarm information
When an alarm setting has been violated the buzzer sounds and the speaker
icon appears (in red on the color model). Press the [CLEAR] key to silence the
alarm. You can see which alarm has been violated on the alarm menu display. In
the example below the arrival alarm has been violated.
1. Press the [ALARM] key. The name of the offending alarm appears in the
ALARM INFORMATION window.
AUDIO ALARM
INT & EXT BUZZ
ARRIVAL ALARM
ON 0.010nm
ANCHOR WATCH ALARM
OFF 0.010nm
PROXIMITY ALARM
OFF
XTE ALARM
OFF 0.050nm
SPEED ALARM
OFF
TRIP ALARM
OFF 0000.0nm
ALARM INFOMATION
ARRIVED
AT WAYPOINT.
ALARM1
EDIT
NEXT
INFO
CLEAR
ALARM
NEXT
PAGE
RETURN
Alarm information
window
Means multiple alarms
have been violated.
CONTINUE
Speaker icon
Alarm menu)
2. Press the CLEAR ALARM soft key to acknowledge the alarm (and silence the
alarm if it was not already silenced with the [CLEAR] key.) For the color
model, the speaker icon changes from red to background color. The icon
remains on the screen until the cause of the alarm is eliminated or the alarm
is disabled.
Note: If more than one alarm has been violated the message CONTINUE
appears at the bottom of the alarm information window. In this case
press the NEXT INFO soft key to see which other alarms have been
violated.
3. Press the [ALARM] key to close the alarm menu.
