FUTABA 7CAP - Programmable Mix Details and Options; Mix Activation: SWITCH and NULL Options; Mix Rate and Offset Adjustment

• Slave: the controlled channel. The channel that is moved automatically in response to the movement of the master
channel. The second channel in a mixís name (i.e. aileron-to-rudder).
• On/off choices:
• S
WITCH: Any of the positions of any of the 5 switches may be used to activate a mix. Up&Cntr, Cntr&Dn options
allow the mix to be ONin 2 of the 3 positions of a 3-position S
WITCH.
• NULL (--):NoS
WITCH can turn this mix OFF.This mix is active at all times.
• Rate: the percentage of the slave
's range it will move upon maximum input from the master channel. Ex: RUDDER-
AILERON mix, 50%. Ail range=1". When rudder is moved full right, ailerons move 1/2".
• Offset:Offsets the slave's center relative to the master. Ex: Smoke valve opens wider per throttle servo position when
smoke SWITCH is ON. Smoke servo's neutral is moved down from THROTTLE STICK center to the bottom.
54
MASTER SLAVE SWITCH & POSITION RATE OFFSET
RUDD AILE NULL (--) 50% center(default)
MASTER SLAVE SWITCH & POSITION RATE OFFSET
THRO CH7 E DOWN 0%(Hi) half throttle(default)
100%(Lo)
*Assign the CH7 switch to NULL(--). See p.28.
