FUTABA 7CAP User Manual

AQUICK INTRODUCTION TO THE 7C SYSTEM
TRANSMITTER:
•
Large graphic liquid-crystal display panel with 4 buttons and an easy set up turn-and-press Dial for quick, easy setup.
•
All transmitters include all 2 aircraft types with specialized programming for each, including:
•
Airplane (ACRO)
•
V-TAIL
•
Twin Aileron Servos (FLAPRN )
•
ELEVON
•
Air Brake
•
Snap Roll
•
Helicopter (6 swashplate types, including CCPM, see page 61)
•
2 Idle Ups
•
Throttle and Pitch Curves per Condition
•
Revo. Mixing
•
Gyro Mixing including Separate Settings per Condition
•
BASIC menu for quick, easy set up of less complex models.
•
ADVANCE menu for more complex, unique setups.
•
Four electronic TRIM LEVERS for rapid yet precise trim adjustment - no remembering to "store trims" between models
and no more "bumped trims" during transport.
•
TH-CUT (AC RO/HELI) (engine shut off) setups to allow precise engine control for taxi and landings.
•
10 complete model memories
•
New stick design with improved feel, adjustable length and tension.
•
Triple rates available by setting dual rates to 3-position switches.
•
Six SWITCHES DIALand 1 ; assignable in some applications.
•
Trainer system includes the "functional" (F )setting, which allows the student to use the 7C's mixing, helicopter, and
other programming functions even with a 4-channel buddy box. (Optional trainer cord required.)
•
Transmits in both FM (PPM)andPCM by selecting modulation/cycling transmitter. Requires receiver of proper modulation.
•
Permanent memory storage via EEPROM with no backup battery to service or have fail.
•
7CA transmitter features airplane friendly switch layout, with the trainer switch at the left hand, and a notched throttle
to minimize throttle changes with rudder input. Defaults to AC R O MODEL TYPE.
•
7CH transmitter features helicopter-friendly switch layout, with idle-up switch at the left hand, and
a smooth, ratchet-less (unsprung) throttle for perfect hovering. Defaults to H-1 MODEL TYPE.
Note that in the text of this manual, beginning at this point, any time we ar e using a featur eís specialized name or abbr eviation
as seen on the scr een of the 7C, that name, feature, or abbreviation will be exactly as seen on the radioís screen, including
capitalization, and shown in a DIFFERENT TYPESTYLE for clarity. Any time we mention a specific control on the radio itself,
such as moving S
WITCH A, KNOB VR,ortheTHROTTLE STICK, those words will be displayed as they are here.
7
•
In North America it is against FCC regulation to change the crystal within the transmitter to a different
channel. All such transmitter crystal changes must be performed by a certified radio technician. Failure to properly tune
a system to its new channel may result in decreased range and may also result in interference to other types of frequency
users on adjoining channels. Doing so also voids your AMA insurance.
