•SET CONTENTS
Model
Transmitter
Receiver
Servos
Switch
Nicd Battery
Misc.
FP-9VAP
FP-T9VAP x 1
FP-R129DPx 1
FP-S9101 x4,orS5101 x4
SSW-J x 1
NR-4J x 1
Battery charger, extension cord, DSC cord, CHG adaptor, DSC-CHG cord,
frequency flag, spare output arms, neck strap, screws
•RATINGS
Transmitter FP-T9VAP Charger PBC-8B (2)
Operating System : Two-stick, 9 Channel, PCM
Transmitting Frequency: 72MHz, 53MHz, 50MHz
Modulation : FM- PCM/PPM selectable.
Power Requirement : 9.6 volt (8/500mAH)
internal
Nicd battery
Current Drain : 230mA
Input Voltage : 1 20VAC, 60Hz, 4W
Output Voltage : TX side 9.6V, 50mA
RX side 4.8V, 50mA
Servo FP-S9101 -5101
Receiver FP-R129DP
Receiving Frequencies
72MHz, 53MHz, and 50MHz
Intermediate Frequency
1st IF : 10.7MHz
2nd IF:455kHz
Power Requirement 4.8 volt Nicd battery (shared
w/servos)
Current Drain 35mA (4.8V reception)
Dimensions 63.0x37.8x24.1mm
Weight 45g(1.6oz.)
Receiving Range 500m (1,500 ft.) ground
1,000m (3,000ft.) air
(When FP-T9VAP used under
best
radiowave conditions)
Control System : + pulse width control
1520uS neutral
Operating Angle : Each direction from neutral -
45 or greater (including trim)
[3]
