PARAMETER
Servo Test: Each servo is operated in linear fash-
ion from neutral, to its maximum and minimum
positions. The operation is repeated sequentially
for Channels 1 through 8.
Mixing Mode: In the BASIC mode, all mixing
circuits except Programmable Mixing are de-
activated. In the AERO mode, all circuits are
useable.
PCM/PPM: PCM or PPM encoding can be select-
ed
with
this
function.
PPM
encoding
allows
the
transmitter to be used with standard FM re-
ceivers.
D/R SW D/R: The ON/OFF directions of the
D/R Switches can be selected. In Mode 1, the
upper position is the D/R ON (low rate) position,
and in Mode 2, the lower position is the ON
position.
9CH SW POS: The position of the CH9 switch
can be selected. In SW POS 1, the CH9 Switch
becomes the RUD D/R switch position. For SW
POS 2, the CH9 Switch position is at the CH5
switch and CH5 is controlled by the CH7 Knob.
(Therefore, when AIL DIFF mixing is used, all 9
channels can be used effectively.)
2) Servo Test: Move the cursor to the SERVO-
to Line 2 with the cursor key, then dis-
play the PARAMETER screen by pressing the
program key.
TEST position with the
cursor or
NOTE: Encoding will not change until the
transmitter is turned OFF and back
ON again.
5) Dual Rate Switch Direction: Move the cursor
to the D/R SW DIR position and select Mode
or program
4) PCM/PPM: Move the cursor to the PCM/PPM
key. Turn the function ON and OFF with the
and program keys.
MODE position with the cursor or
key. Select either the BASIC or AERO mixing
mode by pressing the program or
key.
position with the cursor key and or
3) MIX-MODE: Move the cursor to the MIX-
key.
6) Channel 9 Switch Position: Move the cursor
to the 9CH SW POS position and select SW
POS
1 or 2 with the
program or
key.
7) Return to the EDIT screen by pressing the
program key.
select the desired encoding method by pres-
sing the
program key. or
