V
FUTABA 9Z
THE UNOFFICIAL WORKSHOP MANUAL
WARNING: THE INFORMATION IN THIS MANUAL IS FOR INFORMATION PURPOSES ONLY AND MAY BE INCORRECT, CAUSE DAMAGE
TO YOUR RADIO OR INJURY TO YOURSELF AND OTHERS. IF YOU USE THIS MANUAL YOU DO SO SOLEY AT YOUR OWN RISK.
www.jamesandtracy.co.uk
Copyright 2012 jamesandtracy.co.uk
Page 15 of 84
ID TASK DIFFICULTY SECTION PAGE
Section 3 – SERVICING
1 User Password
3.1 20
2 9Z Transmitter Calibration
3.2 20
3 Replacing Corner Switches
3.3 20
4 Replacing front face controls and switches
3.4 21
5 Removing the throttle ratchet for helicopter flying
3.4.1 21
6 Replacing joysticks and potentiometers
3.4.2 23
7 Replacing the LCD button panel
3.5 28
8 Replacing the 35MHz aerial
3.4 29
9 Backup (Lithium) Battery
3.5 28
10 Cleaning the LCD Screen
3.8 33
11 Replacing the LCD Screen
3.9 34
12 Transmitter battery pack
3.10 35
13 RF Module
3.11 37
14 Hard Resetting the 9Z Back to Factory Settings
3.12 38
Section 4 – UPGRADING
15 Adding extra 3 position switches
4.1 40
16 Tailoring the Reference Plane of Joysticks
4.2 40
17 Strengthening and repairing the Joysticks
4.3 41
18 Backlit LCD Display
4.4 43
19 9Z Mode and Version Change (e.g. ZAP to ZHP)
4.5 44
20 Upgrading to 2.4GHz and Telemetry
4.6 45
21 Cycling and Fast Charging the Transmitter Battery Pack
4.7 51
22 Building a DSC Cable for Direct Servo Control
4.8 54
23
Building your own CAMPAC for increased model
memory
4.9 54
