APPENDIX C. COMPONENT PART NUMBERS
Note: Table 5 is provided as a guide. You should always verify part numbers with the
listed supplier.
Table 5 below provides a list of the key component part numbers used in the procedures
detailed in this manual.
9Z Model Component Supplier Part No. Notes
Hobby Services (Note: Futaba direct part number in brackets, some suppliers exclude the “Y-“)
9Z WC2 Gimbal / Joystick Futaba HSP73839 ST-22B (R)
(Y-TFT1500020)
9ZAW throttle
gimbal inc. aircraft
version ratchet
(i.e. 9ZAW left
hand side gimbal)
9Z WC2 Gimbal / Joystick Futaba HSP73840 ST-22B (B)
(Y-TFT1500021)
9ZHW throttle
gimbal inc.
helicopter version
ratchet (i.e. 9ZHW
left hand side
gimbal)
9Z WC2 Gimbal / Joystick Futaba HSP73841 ST-22B (S)
(Y-TFT1500019)
9ZHW and 9ZAW
gimbal - sprung
only (i.e. right
hand side gimbal)
9Z WC2 Potentiometer Futaba HSP73870 VR ST-22B
(Y-2M41A01602)
Elevator and
throttle axis
9Z WC2 Potentiometer Futaba HSP73871 VR ST-22B
(Y-2M41A01702)
Aileron and
Rudder axis
9Z*p &
WC1
Potentiometer Futaba HSP53710 VR 133-19
(Y-2M41A01701)
Elevator and
throttle axis
9Z*p &
WC1
Potentiometer Futaba HSP53709 9Z VR 133-18
(Y-2M41A01601)
Aileron and
Rudder axis
9Z All Joystick Shafts Futaba (Y-SO1777) Pair of shafts (buy
with Y-SO1773)
9Z All Joystick Inner
Gimbals
Futaba (Y-SO1773) Pair of gimbals
(buy with Y-
SO1777)
9Z WC2 Buttons Label Futaba HSP73853 Bottom middle
9Z WC2 Buttons Label Futaba HSP73855 Right side
