S
PECIFICATIONS
CGY760R
Control System: Digital advanced control
Angular Velocity Range: ±1,000 Degrees Per Second (Gyro)
Sensor:
Micro Electromechanical
Systems (MEMS) Gyro
Hall effect sensor
Governor Resolution: 0.1
Hz (6
rpm) (Engine RPM)
RPM Accuracy: 1%
Head Speed Range: 700-4,000
rpm
Selectable Servo Frame:
70
Hz, 280
Hz and 560
Hz
(Rudder Gyro only) Rate
Center Pulse Width:
1520
μS (70
Hz & 280
Hz)
760
μS (560
Hz)
Receiving system:
FASSTest-2.4
GHz (18
CH/12
CH mode ) / T-FHSS-2.4
GHz
S.BUS2 / S.BUS Port and 6
Channels for Conventional System
Frequency band: 2.4
GHz band
RF power output: 25
mW EIRP
Anntena: Dual antenna diversity
Rated voltage
: 3.7
V to 7.4
V DC* (
Operating Voltage:3.5
V to 8.4
V)
Current Drain: 85
mA (When receiving, no servo, no RPM sensor)
Operating Temperature: 14°F to 113°F (-10°C to +45°C)
Size (CGY760R) :
1.055
in. [26.8
mm](W) / 1.476
in. [37.5
mm](L) / 0.63
in. [16
mm](H)
Weight (CGY760R) : 0.713
oz [20.2
g]
CGY755
Control System: Digital advanced control
Angular Velocity Range: ±1,000 Degrees Per Second (Gyro)
Sensor:
Micro Electromechanical
Systems (MEMS) Gyro
Hall effect sensor
Governor Resolution: 0.1
Hz (6
rpm) (Engine RPM)
RPM Accuracy: 1%
Head Speed Range: 700-4,000
rpm
Selectable Servo Frame:
70
Hz, 280
Hz and 560
Hz
(Rudder Gyro only) Rate
Center Pulse Width:
1520
μS (70
Hz & 280
Hz)
760
μS (560
Hz)
Rated voltage
: 3.7
V to 7.4
V DC* (
Operating Voltage:3.5
V to 8.4
V)
Current Drain: 85 mA (When receiving, no servo, no RPM sensor)
Operating Temperature: 14°F to 113°F (-10°C to +45°C)
Size (CGY755) :
1.055
in. [26.8
mm](W) / 1.476
in. [37.5
mm](L) / 0.63
in. [16
mm](H)
Size (Revolution sensor) :
0.827
in. [21
mm](W) / 0.63
in. [16
mm](L) / 0.39
in. [10
mm](H)
Weight (CGY755) : 0.705
oz [20.0
g]
RPM sensor
Size:
0.827
in. [21
mm](W) / 0.63
in. [16
mm](L) / 0.39
in. [10
mm](H)
Weight: 0.141
oz [4
g]
