61
G
OV.
B
ASIC
M
ENU
(
GOVERNOR BASIC SETTING
)
This menu sets the governor’s fundamental functions. The menu Servo limit point
setting must be set rst.
"
GOV. BASIC
"
screen from the
"
BASIC MENU
"
screen.
GOV. BASIC screen 1/6
From 6/6 From the "SBUS2 rpm Slot"
of GOV. BASIC screen 6/6
Note: When using the governor function, be sure
to make each setting of "GOV.BASIC".
Note: After completing the linkage of the throttle,
be sure to set the "Servo limit point setting" first,
and then set the other functions.
: :
:
Go to 2/6 from any cursor position
(1) Governor: Governor active
Set the governor operation mode of CGY. The initial setting is "ACT
(active)" where, as the designation implies, the governor is active. If
you do not want to use governor, select "INH (Inhibit)".
Setting: ACT (Active) / INH (Inhibit) Initial setting: ACT
(2) Gear Ratio:
Input the main rotor gear ratio by pushing the [ /+] or [ /-] key to select
the desired working mode.
Setting ranges: 1.00 ~ 50.00
t Initial value: 8.00
t
Notes:
• If the gear ratio is not properly set,
the set speed and actual engine
speed will be different.
• The gear ratio should be given in the
helicopter instruction manual. If the
helicopter instruction manual does
not give the gear ratio, calculate the
gear ratio as follows:
Rotor
main gear
N1
Engine
pinion gear
N2
Gear ratio = N1/N2
Carry values less than 1/1000 to the
next whole number.
To Next Page
