＜ Linkagemenu ＞
*It cannot be used in FASST mode and S-FHSS mode.
*Only receiver voltage and EXT voltage can be used in
FASSTest12CH mode.
*The FASSTest18CH /T-FHSS mode can use all the telemetry
functions.
Telemetry:Voltage[Battery]
Displaying data from the receiver battery voltage
In this screen, the battery voltage of a receiver is
displayed.
If it becomes higher or lower than the settin, an
alarm and/or vibration will alert you.
Batteryvoltage
Setsthevoltageon
whichthealarm
operates.
↓ The"down"arrow
willindicatethatan
alarmwillsoundwhen
thevoltagedropsto
belowthesetting.
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
ŏ Tap the [Voltage] button in the Telemetry screen
to call the setup screen shown below.
Max.andmin.values
sincethepower
wasturnedONwill
display.
In this screen, the battery voltage is displayed.
In order to use this function, it is necessary to
connect External voltage connector of R7008SB
⇔
SBS-01V
⇔
Battery
SBS-01V measures two batteries. The power
battery connected to two lines is displayed on EXT-
VOLT. The battery for receivers connected to 3P
lines is displayed here.
*SBS-01Vmustbeinstalledintheaircraft.
＜
Two examples of wiring are shown
＞
*Refer to the manual of SBS-01V for the details of
wiring.
WR6%86
SRUW
WR6%86
SRUW
56%
56%
Drivebattery1
（EXTBattery)
Receiverbattery
Receiverbattery
Drivebattery2
（EXTBattery)
Drivebattery1
（EXTBattery)
Drivebattery2
（EXTBattery)
6ZLWFK
Powersupplies
forservos
$QRWKHUSRZHU
VXSSO\+XE
S.BUS2
servos
Twodrivebatteriesaremeasured(R7008SBuse)
Twodrivebatteriesandpowersuppliesforservosaremeasured(R7008SBuse)
●Batteryvoltagemeasurementforreceivers[R7008SBuse]
●Thedrivebattery1ismeasuredinanEXTport[R7008SBuse]
●Thedrivebattery2ismeasuredinanEXTline[SBS-01Vuse]
●Batteryvoltagemeasurementforreceivers[R7008SBuse]
●Thedrivebattery1ismeasuredinanEXTport[R7008SBuse]
●Thedrivebattery2ismeasuredinanEXTline[SBS-01Vuse]
●Thevoltageforservosismeasuredinapowersupplyline[SBS-01Vuse]
Normal Line
Normal Line
EXT Line
EXT Line
*SBS-01Vmeasurestwovoltage.Onecorrespondstohighvoltages,suchasadrivebattery,
withanEXTline.Anotherisanormallineandismeasurementofthebatteryforreceiversofa
lineconnectedto3Pconnector,orthebatteryforservos.
Alarm set
1. Tap Alarm and choose from Bu]]er,
Voice, and Inhibit.
2. Choose "Inhibit" for Vibrator if no
t
using
the vibrator alarm. If using vibrator,
choose one of the three types.
3. Tap to the Limit [4.0V] item .
4. Adjust the rate using the "ʈʈ" "ʈ" "ʆ"
"ʆʆ" buttons.
Initial value: 4.0V
Adjustment range: 0.0V~100.0V
*When the screen is tapped for one second, the rate is
reset to the initial value.
5. To terminate the input and return to the
original state, push the H/E button.
Vibratorchoicesare
type1-3,andInhibit.
ŏReturn to
Linkage menu
