FUTABA FX-36 - Page 104

104
＜ Linkagemenu ＞
Telemetry:Voltage[Ext.battery]
Alarm set
1. Tap Alarm and choose from Bu]]er, Voice,
and Inhibit.
2. Choose "Inhibit" for Vibrator if no
t
using the
vibrator alarm. If using vibrator, choose one
of the three types.
3. Tap Limit [4.0V].
4. Adjust the rate using the "ʈʈ" "ʈ" "ʆ" "ʆʆ"
buttons.
Initial value: 4.0V
Adjustment range: 0.0V~100.0V
*When the screen is tapped for one second, the rate is reset to
the initial value.
5. To terminate the input and return to the
original state, push the H/E button.
Setsthevoltageon
whichthealarm
operates.
↓ The"down"arrow
willindicatethatan
alarmwillsoundwhen
thevoltagedropsto
belowthesetting.
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
ŏ Tap the [Voltage] button in the Telemetry screen to
call the setup screen shown below.
Max.andmin.values
sincethepower
wasturnedONwill
display.
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
Displaying data from the EXT
battery voltage port
In this screen, the EXT battery voltage is
displayed.
In order to use this function, it is
necessary to connect External voltage connector of
R7008SB
⇔
SBS-01V
⇔
Battery
SBS-01V measures two batteries. The power
battery connected to two lines is displayed on EXT-
VOLT.
*SBS-01Vmustbeinstalledintheaircraft.
*It cannot be used in FASST mode and S-FHSS mode.
*Only receiver voltage and EXT voltage can be used in
FASSTest12CH mode.
*The FASSTest18CH /T-FHSS mode can use all the telemetry
functions.
Ext.battery
voltage
ŏReturn to
Linkage menu
