＜ Linkagemenu ＞
Telemetry:GPS[Speed]
Displaying data from the speed
The speed screen displays and sets the speed data from an
SBS-01/02G (GPS sensor) sold separately.
The speed of the aircraft during Àight can be displayed.
After flight, the maximum speed during flight can be
viewed. Because this speed is based on position data from
a GPS satellite, the ground speed is displayed instead of
air speed. Consequently, with a head wind, the displayed
speed decreases and with a tail wind, the displayed speed
increases.
*AGPSsensormustbeinstalledintheaircraft.
Alarm setting when speed increases
1. Tap Alarm and choose from Bu]]er, Voice, and
Inhibit.
2. Choose "Inhibit" for Vibrator if no
t
using the vibrator
alarm. If using vibrator, choose one of the three
types.
3. Tap Limit [xxx km/h].
4. Adjust the rate using the "ʈʈ" "ʈ" "ʆ" "ʆʆ"
buttons.
Initial value: Ń200km/h Ņ0km/h
Adjustment range 0km/h~500km/h
(ŃLimit
≧
ŅLimit)
*When the screen is tapped for one second, the rate is reset
to the initial value.
5. To terminate the input and return to the original
state, push the H/E button.
*Speed alarm precaution
Since the GPS speed sensor displays the ground speed, it
cannot be used as a stall alarm. For example, an aircraft that
stalls at 50km/h will stall if the tailwind is 5km/h or greater
even through 55km/h is displayed by ground speed. In
addition, with an aircraft that will disintegrate in midÀight at
400km/h at an over-speed alarm, when the headwind reaches
30km/h the airplane will disintegrate in midair due to over
speeding even at a ground speed of 370km/h.
Setsthespeedon
whichthealarm
operates.
ŏ Tap the [GPS] button in the Telemetry screen to call
the setup screen shown below.
Max.andmin.values
sincethepower
wasturnedONwill
display.
Speed
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
*The GPS sensor is necessary, and is sold separately. Mount
and connect the sensor in accordance with the sensor
instruction manual.
*It cannot be used in FASST mode and S-FHSS mode.
*Only receiver voltage and EXT voltage can be used in
FASSTest12CH mode.
*The FASSTest18CH /T-FHSS mode can use all the telemetry
functions.
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
speedreachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
speedreachesbelow
yoursetvalue.
ŏReturn to
Linkage menu
ReferenceandDistancemodeworkinconjunction
withDistancediscussedontheprevioustwopages.
