＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
ELEVATOR
ELEVATOR2
(AILERON5)
(AILERON6)
Ailevator
[Corresponding model type]: Airplane/glider, Tail type
Ailevator
(Effective only when 2 servos used at the elevators)
This function improves the operating
performance of the roll axis by operating the
elevators as ailerons.
Ailevator is where each elevator in a standard
(conventional) or v-tail moves independently, like
ailerons on a wing. In addition to each elevator side
moving up and down together, each side moves in
opposite directions when moving as an ailevator.
On a V-tail, this is also known as a ruddervator,
as they can serve the same purpose. Typically,
both ailevator and ailerons are coupled together to
maximize roll performance, especially on larger
wingspan planes.
Note: Select ailevator as the Model type at the
Model type screen. This changes the output
channel. Check the Function menu.
ŏ Select [Ailevator] at the model
menu and call the setup screen
shown below.
ŏ Travel adjustment
Tap to the item you want to adjust.
Adjust the rate using the "ʈʈ" "ʈ" "ʆ" "ʆʆ"
buttons.
*If the mixing direction is reversed by the linkage,
adjustments can be made by changing the mixing rate
polarity (+ or -).
*If a large value of travel is speci¿ed, when the sticks are
moved at the same time, the controls may bind or run out
of travel. Decrease the travel until no binding occurs.
(Aileronfunction)
Whentheelevatorsareusedas
ailerons,ailerontraveloftheleftand
rightelevatorscanbeadjusted.
(Elevatorfunction)
Theupanddownratesoftheleftand
rightelevatorswhentheelevatorstickis
manipulatedcanbeindividuallyadjusted.
Conditiongroup/
singlemode
selection(Gr./Sngl)
ŏReturn to Model menu
