37
GYRO UPDATE (Update mode of CGY)
This menu is used to adjust the update mode of the CGY. The mode selected will be
determined by the model of the CIU selected and personal preference. For example,
when using the CIU-3, the user may select either the high speed or the slow speed
modes. If using the CIU-2, only the slow speed mode is available.
* The following optional products are required for the update.
· CIU-2 or CIU-3
· Cable for CGY760R/CGY755/GY701/GY520 or DSC cable for update
(1) Download CGY760R/CGY755 update le
Download the CGY update file from our website or your local distributor's website.
(2) Preparation for update -1
Connect the CGY, GPB-1, CIU-2 or CIU-3 to the PC with ref-
erence to the above connection diagram.
To the open/available slot of CGY
GPB-1
CGY
A PC that can connect to the
Internet and has CIU-2 or CIU-
3 driver software installed.
Double extension cable
When there is no connector
to connect power to CGY
Switch
Switch
connector
Battery
CIU-2 or CIU-3
To PC USB port
To CIU-2
or
CIU-3
To S.B2 port of CGY
Connect cable to S.B2 port of CGY
To P.BOX port of CGY
NOTE: Updating can NOT be performed when the
transmitter and the CGY760R communicate or when "Internal Rx" set-
ting is INH. Turn on the power of the CGY760R with "Internal Rx" being
ACT and transmitter power OFF.
For CGY760R
