76
(5) ANG: Pirouette speed
This parameter adjusts the maximum pirouette speed of the tail rotor
that the gyro will allow at 100% dual rate. Use the [
/+] or [ /-] key to
adjust the maximum commanded pirouette rate.
Setting ranges: 100 ~ 999
d Initial value: = 720
d,
(6) F/F.Rate U / F/F.Rate D: F/F mixing rate
Feed Forward mix is used to counteract sudden increases in torque from
the motor during fast collective pitch changes. If you notice a tail kick, using
(right rudder on Clockwise rotor disk, left rudder on CCW) F/F mixing can
be tuned to reduce the tail kick. The mixing amount can be individually set
for high pitch side (U) and low pitch (D) side with zero pitch as the center.
Setting ranges: -100 ~ 0 ~ +100% Initial value: +0%
RUD. EXPERT screen 3/5
RUD. EXPERT screen 4/5
Go to 4/5 from any cursor position
Go to 5/5 from any cursor position
From 2/5
From 3/5
