FUTABA T32MZ Manual

3
B.Wirelesstunings:Gyrotuningscanbemadewirelessly.(Limiteditems)
T32MZ
CGY755/CGY760R
ForCGY755
(ForCGY760RUseotherreceiver)
S.BUS2Receiver
WirelessTuningsfunctionlist
Donotsetduringflight.Makesettingswhen
theaircraftisonthegroundandthemotor
andenginearestopped.
-FLT. TUNE
Base Gain: Gyro base gain setting
CYC. Rt: Cyclic rate setting
Cnt. AuthAIL: Control Authority Aileron
Cnt. AuthELE: Control Authority Elevator
EXPO.: Exponential
FLT. Styl: Flight style
ELE. Comp: Elevator pre compensation
-SWH. BASIC
SWS. Rate: Rate adjustment
PIT. Rate: Rate adjustment
SWS. Ring
- GOV. BASIC
GOV Gain: Governor gain
L Lmt. L rpm : Low limit hovering RPM
L Lmt. H rpm : Low limit idling RPM
-FLT. EXPERT
HeadHld A : Head hold aileron
StopTune A : Stop tune aileron
HeadResp: Head Response
HeadHld E: Head hold elevator
StopTune E : Stop tune elevator
-RUD. EXPERT
EXP. AVCS: Rudder exponential AVCS
EXP. NORM: Rudder exponential NORMAL
CNT. DlIn: Control delay in
CNT. DlOut: Control delay out
ANG: Pirouette speed
Tail Resp: Tail response
A.Wiredconnection:Advancedsettings(allfunctionssameasGPB-1)
T32MZ
S.I/F
P.BOX
CGYConnectionCable(includedwithgyro)
CGY755/CGY760R
● Connectthereceiverbattery(3.5to8.4  V)to
oneofthe"AIL"to"S.B2"connectorsother
than"RPM"and"P.BOX".
(Donotconnectto"RPM"and"P.BOX".)
Notes
IftheT32MZandgyroarenotconnected,the
gyrosettingvaluecannotbechanged.
Notes
Whenusingthewirelesstuningfunction,set
thetelemetryfunctiontoACT.
ThewirelesstuningcanbeFASSTestorT-FHSS.
