11 SEAT TO FLOOR
590 REV02 REV DATE: SEPTEMBER 13, 2013 30 AQUA NT
11 Seat to Floor
Adjusting the seat to floor ratio Figure 15 Table 1
WARNING
After ANY adjustments, repair or service and BEFORE
use, make sure all attaching hardware is tightened
securely – otherwise injury or damage may occur.
Seat To Floor
1. Follow the values in the table below to achieve
the desired seat to floor height.
The Front Caster and Rear Caster Should be
set to the same height
2. Ensure that no weight is on the commode while
performing the operations
3. Ensure after changing the seat to floor height
that the commode is still operational and that
no wheel flutter or instability occurs.
4. There are 2 possibilities for commode
assemblies
1) Attendant Propelled – 4 Tente Casters
2) Self-Propelled – 2 Tente Front Casters
To Next Page
