10 ANTI-TIPPERS – SELF PROPELLED
590 REV02 REV DATE: SEPTEMBER 13, 2013 27 AQUA NT
10 Anti-tippers (self-propelled only)
Installing/adjusting anti-tippers Figure 13 Figure 15
WARNING
After ANY adjustments, repair or service and BEFORE use,
make sure all attaching hardware is tightened securely –
otherwise injury or damage may occur.
Installing/Adjusting The Anti-Tippers
WARNING
Anti-tippers are specific to the different seat-to floor angles
and/or seat-to-floor heights for self-propelled commodes only.
Refer to the chart in this section of the manual for correct
usage and adjustment. If these requirements CANNOT be
achieved, DO NOT use the commode. Contact a qualified
technician. If changing the seat-to-floor height with or without
a change to seat-to-floor angle, the correct anti-tippers MUST
be used to maintain a 1 ½“to 2” ground clearance.
Seat-to-floor angle of 3 degrees to 6 degrees: if so equipped,
anti-tippers MUST be attached at all times. In as much as the
