COMMAND SET
Customer Pole Display CD-220 VFD 24
ESC [ A 1B 5B 41 Move cursor up
US LF 1F 0A Move cursor up
ESC [ B 1B 5B 42 Move cursor down
LF 0A Move cursor down
ESC [ H 1B 5B 48 Move cursor to home position
HOM 0B Move cursor to home position
ESC [ L 1B 5B 4C Move cursor to top-left position
CR 0D Move cursor to top-left position
ESC [ R 1B 5B 52 Move cursor to top-right
position
US CR 1F 0D Move cursor to top-right
position
ESC [ K 1B 5B 4B Move cursor to bottom position
US B 1F 42 Move cursor to bottom position
ESC # n 1B 23 n
n=31h~37h
Command type select
US @ 1F 40 Execute self test
US E n 1F 45 n
n=00h~FFh
Blink display screen
n=00h for no blink
ESC l x y 1B 6C x y
1≦x≦14h
y=01h, 02h
Move cursor to specified
position
x= column position
y= row position
US $ x y 1F 24 x y
01h≦x≦14h; y=01h, 02h
Move cursor to specified
position
ESC @ 1B 40 Initialize display
ESC W s x1 x2 y 1B 57 s x1 x2 y
01h≦x1≦x2≦13h
y=01h, 02h, s=00h, 01h
Set/Cancel the window range at
horizontal scroll mode
x= column position
y= row position
CLR 0C Clear display screen and clear
string mode
CAN 18 Clear cursor line and clear string
mode
ESC * n 1B 2A n
01h≦n≦04h (=brightest)
Brightness adjustment
US X n 1F 58 n
01h≦n≦04h (=brightest)
Brightness adjustment
ESC & s n m
[a(p1..pa)]x
(m-n+1)
1B 26 1 n m
[a (p1..pa)] x (m-n+1)
20h≦n≦m≦ FFh
1≦a≦5 p1...p5=row1...row5
Define download characters
