7. Technical Data
Tech
nical Parameters of Brake Li
ning
Name Parameters
Wear limit for front brake lining (excluding its backing
plate)
2mm
Wear limit for rear brake lining (excluding its backing
plate)
2mm
Wheel Alignment Number
Name Parameters
Front Wheel
Toe-in of single wheel 3′±3′
Wheel camber -21′±30′
Kingpin caster angle 7°16'±30′
Kingpin inclination angle 13°±30′
Rear Wheel
Toe-in of single wheel 4′±30′
Wheel camber -55′±30′
Battery
Model Valta T5
Parameters
Rated voltage 12V
20hr rated capacity 55Ah
Low-temperature start current (EN) 530A
Fuse
Instrument Panel Fuse Box => Refer to Page 404
Engine Compartment Fuse
Box
=> Refer to Page 407
Lights
Lights Parameters
Front combination
light
High beam H712V55W
Low Beam H712V55W
Daytime Running
Light*
LED13.5W
Front position light LED1.34W
Front turn signal light 12VWY21W
Front Fog Light* H1612V19W
Guest greeting light * LED 0.5W (total power: 1.44W)
Rear-view mirror side turn signal light LED 0.5W (total power: 1.44W)
Rear combination
light
Rear Fog Light 12VW21W
Rear position light LED A: 6.75W/B: 2W
Rear turn signal light 12VWY16W
Reversing light 12VW16W
Brake Light 12VP21W
Number Plate Light 12VW5W
High brake light LED3W
Front roof lights 12VW8W
Rear Roof Lights* 12VC8W
Courtesy Light* Philips 1207 12V 5W
Glove Box Light 12VC5W
Trunk Light 12VW5W
Atmosphere Light* LED0.2W
