8. Handling of Accident
No.
Rated
Value
Function/Component
IF1 SHORT PIN Short pin
IF2 20A Body control module (light power supply)
IF3 7.5A Gateway control unit
IF4 10A Body control module (turn signal power supply)
IF5 15A AUDIO Control Unit
IF6 15A Sunroof Control Unit
IF7 7.5A
Trunk light / front left courtesy light / front right courtesy
light / rear-view mirror folding relay / rear-view mirror
unfolding relay
IF8 15A Body Control Module
IF9 - -
IF10 - -
IF11 - -
IF12 20A
Body control module (front left window regulator power,
rear left window regulator power)
IF13 20A
Body control module (front right window regulator
power, rear right window regulator power)
IF14 30A IG1 relay/ACC relay/Ignition switch
IF15 20A Front left seat connector (seat adjustment power)
IF16 7.5A OBD Diagnostic Interface
IF17 - -
IF18 10A
Instrument cluster / T-BOX control unit / panorama
parking control unit
IF19 15A Body control module (wiper cleaning power)
No.
Rated
Value
Function/Component
IF20 20A Front left seat connector (seat heating power)
IF21 - -
IF22 20A Body control module (door lock power supply)
IF23 - -
IF24 20A Cigarette Lighter
IF25 7.5A Body control module / PEPS control unit
IF26 10A AUDIO control unit / rear-view mirror adjustment switch
IF27 7.5A
Smartphone wireless charging module / USB charging
port
IF28 - -
IF29 7.5A
Blower relay / electronic anti-glare rear-view mirror /
PEPS control unit / defogging relay
IF30 7.5A
Gateway control unit / body control module / PEPS
control unit
IF31 10A
Sunroof control unit / rain and light sensor / front central
console panel / T-BOX control unit / instrument cluster /
A/C control unit / front left seat connector / left
dashboard switch group
IF32 7.5A
Steering angular speed sensor / EPB control unit /
TPMS control unit / EPS control unit / ABS/ESP control
unit
IF33 7.5A
Front left combination light (adjustment motor) / front
right combination light (adjustment motor) / reversing
radar control unit / panorama parking control unit /
headlight height adjustment switch / anion generator /
A/C control panel
IF34 10A Supplemental Restraint System Control Unit
343
