GALI A-45 - Other Elements



-
-
-33--33-


12.3.- OTHER ELEMENTS12.3.- OTHER ELEMENTS
-SERVO-INTERLOCK: Ref. -SERVO-INTERLOCK: Ref. 52020755202075
POS. POS. REF. REF. DESIGNATION DESIGNATION QUANT. QUANT. OBS.OBS.
1 1 5202076 5202076 CILINDER CILINDER BODY BODY 11
2 2 5202077 5202077 INTERMEDIATE INTERMEDIATE BODY BODY 11
3 3 5202078 5202078 COVER COVER BODY BODY 11
4 4 5202079 5202079 PLUNGER PLUNGER WITH WITH GUIDE GUIDE 11
5 5 5202080 5202080 PLUNGER PLUNGER 11
6 6 5202081 5202081 SPRING SPRING 11
7 7 0301302 0301302 O-RING O-RING 1 1 SET SET OF OF SEALSSEALS
8 8 0070425 0070425 ALLEN ALLEN SCREW SCREW 44
9 9 0070430 0070430 ALLEN ALLEN SCREW SCREW 44
10 10 5202112 5202112 SEAL SEAL “U” “U” 1 1 SET SET OF OF SEALSSEALS
