AMP-43540 (-D3540, -D3520)
Description
The AMP-43540 is a sinusoidally commutated, 16 bit PWM amplifier. It can also be ordered in a two axis
configuration specified as -D3520. The AMP-43540 can be configured for the motors below with just a few
commands.
• Brushless Motors
• Brushed Motors
WARNING
Do not “hot swap” the motor power or supply voltage power input connections. If the amplifier is
enabled when the motor connector is connected or disconnected, damage to the amplifier can
occur. Galil recommends powering the controller and amplifier down before changing the connector,
and breaking the AC side of the power supply connection in order to power down the amplifier.
Chapter 5 Integrated Components ▫ 24 DMC-40x0 UL Installation Manual
