Galil Motion Control DMC-4040 - Mechanical Specifications; Dimensions and Mass; Cabling

Mechanical Specifications
Dimensions and Mass
Controller
Mass
kg (lbs)
Dimensions
cm (in)
DMC-4040-C022-I000-D3x40 1.33 (2.94)
20.45 x 18.42 x 3.58
(8.05 x 7.25 x 1.41)
DMC-4040-C022-I000-D3740 1.69 (3.72)
20.45 x 23.50 x 3.58
(8.05 x 9.25 x 1.41)
DMC-4080-C022-I000-I000-D3x40-
D3x40
2.03 (4.48)
51.94 x 18.42 x 3.58
(11.50 x 7.25 x 1.41)
DMC-4080-C022-I000-I000-D3740-
D3740
2.55 (5.62)
51.94 x 23.50 x 3.58
(11.50 x 9.25 x 1.41)
DMC-4040-C022-I000 1.23 (2.71)
20.45 x 18.42 x 3.58
(8.05 x 7.25 x 1.41)
DMC-4080-C022-I000-I000 1.83 (4.03)
51.94 x 18.42 x 3.58
(11.50 x 7.25 x 1.41)
Table 2.3: DMC-40x0 Mass/Dimensions Specifications
Note – Dimensional drawings for each variant of the DMC-40x0 controller can be found in Chapter 3 under the
Mounting the Controller section.
Cabling
IO Single Core Wire Gauge (AWG)
Digital I/O 24
Analog I/O 24
Power IN (6-pin)
-D3040, -D3240, -D3540,
-D3547
12
Power OUT (4-pin)
-D3040, -D3240, -D3540,
-D3547
16
Power IN (6-pin)
-D3640, -D4040, -D4140
16
Power OUT (4-pin)
-D3640, -D4040, -D4140
18
Power IN (6-pin)
-D3740
8
Power OUT (4-pin)
-D3740
12
Power IN (2-pin)
DMC-4040, DMC-4080
18
Table 2.4: IO Cabling Requirements
Note – Cabling available from Galil may or may not meet the above requirements. For technical support, contact
Galil Motion Control to speak with an Applications Engineer.
Chapter 2 Specifications▫ 3 DMC-40x0 UL Installation Manual
