RJ45 Connector - Ethernet
The Ethernet connection is Auto MDIX, 100bT/10bT.
Pin # Signal Name
1 TXP
2 TXN
3 RXP
4 NC
5 NC
6 RXN
7 NC
8 NC
On the each Ethernet port there are two LEDs that indicate the status of the port's Ethernet connection.
Green Link LED (LNK): The green LED indicates there is a valid Ethernet connection. This
LED will show that the physical Ethernet layer (the cable) is connected. This LED
will also blink to show both transmit and receive activity across the connection.
Orange LED (SPD) : The orange LED indicates the speed of the Ethernet connection. It will be
illuminated for a 100bT connection, and will be off for a 10bT connection.
Jumper Description for CMB-41022
Jumper Label Function (If jumpered)
Option Jumper OPT Reserved
Motor Off Jumper MO When controller is powered on or reset, Amplifier Enable lines
will be in a Motor Off state. A SH will be required to re-enable
the motors.
Baud Rate Jumper 38.4K Baud Rate setting – see the table below
Baud Rate Jumper 19.2K Baud Rate setting – see the table below
Firmware Upgrade Jumper UPGD Used to upgrade the controller if the unit becomes
unresponsive.
Master Reset Jumper MRST Master Reset enable. Returns controller to factory default
settings and erases EEPROM. Requires power-on or RESET to
be activated.
Baud Rate Jumper Settings
19.2 38.4 BAUD RATE
ON ON 9600
ON OFF 19200
OFF ON 38400
OFF OFF 115200
RS-232 Configuration Jumpers
Location Label Function (If jumpered)
JP3 ARXD RS-422 Option Only
ACTS
JP2 MRXD
MCTS
JP3 APWR Connects 5V to pin 9 of the RS-232 Auxiliary Port
Chapter 5 Integrated Components▫ 41 DMC-40x0 UL Installation Manual
