INSTALLATION INSTRUCTIONS
1. Open the energizer
2. Connect the ba ery
3. Close cover and  ghten screw
4. Install energizer
The solar panel should face towards the equator. i.e. in the northern
hemisphere, panel faces south, in the southern hemisphere, panel faces
north. Avoid placing in a shady area.
Push red
ba ery lead
onto red
terminal
